Shelf holder, attaches directly to TondoQuadro square slotted profiles. Indicated maximum load refers only to brackets, for the shelf depends on material chosen (glass shelf not allowed). Maximum length allowed for shelves: 49” 1/64 / 124.5 cm
Cantilever bar, attaches directly to TQ Illuminated slotted profiles. Fits between two TondoQuadro profiles with 186,5 cm (73 27⁄64″) between centers. Black plastic protection included.
Crossbar with cantilever arms, attaches directly to TondoQuadro slotted square profiles. Fits between two TondoQuadro profiles with 124,5 cm (49 1⁄64“) between centers. Black plastic protection included.
Cabinet, fits directly inside profile 085000. Features patent pending locking system includesback/front 122x35cm(48”x13 3/4”) frames and 4 38cm(15”) connecting pins. Accepts panels085200/085202; shelf 085301 when used in the vertical position. Maximum accepted thicknessesof panels: metal 1mm/ 1/32” or acrylic/ wood 6mm/ 7/32”. Maximum load: 40kg / 88 lbs when used in the horizontal position, 90kg […]
Crossbar with cantilever arms, attaches directly to TondoQuadro slotted square profiles. Fits between two TondoQuadro profiles with 64,5 cm (25 25⁄64“) between centers. Black plastic protection included.
Cabinet, fits directly inside profile 085000. Features patent pending locking system includes back/front 61x35cm/ 24”x13 3/4” frames and 4 38cm/ 15” connecting pins.Accepts panels 085200/085201; shelf 085301 for vertical use. Maximum accepted thicknesses of panels: metal 1mm/ 1/32a” or acrylic/wood 6mm/ 7/32”.
Wall mounted aluminium rail. Recommended distance between rails: 14 3/8”/365mm. Recommended max evenly-distributed load: 264lbs/ 120 Kg. Fixing hardware and wall must be capable of taking the indicatedload. Fasteners not included. Rail’s channel accepts graphic panels 33,5cm 13 3/16 H ; 6mm 7/32 D. Requires end caps 085007. Please call your ALU representative for custom […]
